FEATURES AND BENEFITS |
||||
|---|---|---|---|---|
| Metal + Plastic Housing | Up to 2592×1520@25fps | IH+265/ H.265/H.264 | Min. illumination Color: 0.002Lux@F1.6 | 120dB WDR |
| Smart IR Range: Up to 50M | Support tripwire and perimeter | Built-in Mic, SD Card Slot, Reset Button | Operating Conditions -35°~65°, 0~95% RH | POE, IP67 |
SPECIFICATIONS
| MATERIAL SPECIFICATIONS | |
|---|---|
| CAMERA | |
| Image Sensor | 1/2.8” CMOS |
| Signal System | PAL/NTSC |
| Min. Illumination | Color: 0.002Lux@ (F1.6, ACG ON), B/W: 0Lux with IR |
| Shutter Time | 1s to 1/100,000s |
| Day & Night | Dual IR Cut Filter with Auto Switch |
| Wide Dynamic Range | 120dB |
| Angle Adjustment | Bracket, pan 0~360°, tilt 0~75°, roate 0~360° |
| LENS | |
| Lens Type | Fixed |
| Focus | 4mm |
| Lens Mount | M12 |
| Aperture | F1.6, Fixed |
| FOV | Horizontal field of view: 93.8° (2.8mm)/78° (4mm) |
| ILLUMINATOR | |
| IR LEDs | 2 |
| IR Range | Up to 50m |
| Wavelength | 850nm |
| COMPRESSION STANDARD | |
| Video Compression | IH+265/H.265/H.264 |
| Video Bit Rate | 32Kbps~6Mbps |
| Audio Compression | G.711/G.711U/ADPCM |
| Audio Bit Rate | 8K~48Kbps |
| IMAGE | |
| Max. Resolution | 2592×1520 |
| Main Stream | PAL: 25fps (2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720) NTSC: 25fps (2592×1520, 2560×1440), 30fps (2304×1296, 1920×1080, 1280×720) |
| Sub Stream | PAL: 25fps (704×576, 704×288, 640×360, 352×288) NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
| Image Setting | Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement | BLC/3D DNR/HLC |
| OSD | 16×16, 32×32, 48×48, 64×64, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions |
| Privacy Mask | Yes, 4 regions |
| Smart Defog | Yes |
| FEATURE | |
| Alarm Trigger | Motion Detection, Mask Alarm, IP Address Conflict |
| Video Analytics | Tripwire, Perimeter |
| NETWORK | |
| ANR | Yes, auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection (Only Support Impact Series ANR Support NVR) |
| Protocols | TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, MULTICAST, IPV4, NTP, UDP, Telnet |
| System Compatibility | ONVIF (PROFILE S/T/G) |
| Remote Connection | ≤7 |
| Client | IH-View |
| Web Version | Web5 |
| INTERFACE | |
| Communication Interface | 1 RJ45 10M/ 100M self adaptive Ethernet port |
| Audio I/O | Mic in |
| Reset Button | Yes |
| On-board storage | Built-in MicroSD card slot, up to 512 GB |
| GENERAL | |
| Web Client Language | English |
| Operating Conditions | -35oC~65oC, 0~95% RH |
| Power Supply | DC 12V±25%, PoE (802.3af) |
| Power Consumption | MAX: 6W (12V) MAX: 7W (PoE) |
| Protection | IP67, Lightning protection, surge protection and voltage transient protection |
| Dimensions | 160.8 68×74.5mm (6.33 2.68 2.93inch) |
| Weight | Metal+Plastic: 0.3Kg (0.66lb) Metal: 0.48Kg (1.06lb) |
* Listed resolutions are only selectable options. It does not mean that all streams can work at their maximum resolution at the same time.
