Specification |
Biometric Access Control Hardware Architecture |
Device with inbuilt Controller |
Type of Biometric Device |
Finger Print Scanning |
Biometric Access Control Software Architecture |
Web Based (On premise server solution) |
Types of Biometric Credentials Required |
Finger + RFID Card |
Type of RFID Card Supported |
EMProx |
Maximum Fingerprint Template Storage Capacity (Number) |
9600 |
Maximum Palm Templates Storage Capacity in Palm Vein Device (Number) |
0 |
Screen Type |
Non Touch |
Microcontroller |
32 bit |
RAM (MB) |
256 |
Storage (GB) |
4 |
USB Ports for Communication/Data Transfer |
yes |
If Yes, Number of USB Ports |
1 |
LAN Connectivity |
yes |
If Yes, Type of LAN Connectivity |
Ethernet 10/100/1000 |
Wi-Fi Connectivity |
yes |
If Yes, Type of Wi Fi Connectivity |
802.11 a/b/g/n |
Type of Data Supported |
4G/Lte |
Auxiliary Input/output Ports |
yes |
Tamper Detection |
yes |
Buzzer |
yes |
External Reader Support |
no |
Exit Switch Support |
no |
Door Lock Supported |
no |
Type of Lock Supported |
no |
Biometric Matching Modes Supported |
1 : N |
Operating System Support |
Windows 64-bit |
Database Server Support |
MS SQL 2012 Standard |
Web based User Friendly GUI Application |
yes |
DE Duplication function at local and central level |
yes |
Any time anywhere Enrolment |
yes |
Anyone anywhere Access |
yes |
Real-time monitoring of door controllers from centralized location |
yes |
Automatic Template Distribution of Biometric Templates on Assigned Devices to User |
yes |
Automatically push the data to server by the door controller |
yes |
API Support for Third Party Software Integrations |
yes |
SMS Notifications Supported |
no |
E-mail Notifications Supported |
no |
Automatic E-mail Scheduler Facility for Different Reports |
no |
Automatic Database Backup Facility at Scheduled Time |
yes |
Backend Database support |
MS SQL 2008 R2 |
Multi Location Connectivity |
yes |
E map Feature |
yes |
Security Guard Tour Feature Support |
no |
Employee Anti-pass back Feature Support |
no |
Door Interlocking Support |
no |
2 Person Authentication Feature for Secured Area |
no |
Customized Report Generation Facility |
yes |
Employee specific Multiple Access level Support |
yes |
Network Based Integration with External Access Barrier Devices |
no |
Support of Integration with Video Surveillance |
no |
Elevator Access Control Feature Support |
no |
Fire Alarm Integration Support |
no |
BIS Registration Under CRS of Meity |
yes |
BIS Registration Number and its validity |
na |
RoHS Compliance |
yes |
Other Certifications Available |
CE |
Type Test Certificate Covering all parameters and Environmental tests from STQC certified lab |
no |
If Yes, TTC Number and Date |
na |
If Yes, Name of the Lab |
na |
If Yes, Address of the Lab |
na |
Power Source Requirement |
230 V +/- 10% V AC, 50 Hz |
Battery Backup Unit Support |
yes |
Installation and commissioning is included in the scope of supply |
yes |
Warranty (Years) |
1 |
