Key Features-
- Intel Processor
- Max 16 IP Camera Inputs with IVS Recording
- Max 180/180 Mbps Incoming/Outgoing Bandwidth
- Up to 8MP Resolution for Preview and Playback
- Expanded Storage Space
- Smart Tracking
- Intelligent Video System with Business Analytics (Two IP Channels)
- Dual-OS Design to Ensure High Reliability of System Running
- 264+ Compression Effectively Reduces the Storage Space and Costs by up to 50%
- HDMI1/VGA1 and HDMI2/VGA2 Outputs Provided
- HDMI1 Video Output at up to 4K (3840×2160) Resolution
- Up to 1 SATA Interfaces for Recording and Backup
| Feature | Details |
| Processor: | Industrial-Grade Embedded Processor |
| IP Camera Input: | 16 Channel |
| Operating System: | Embedded LINUX |
| Two-way Talk: | 1 channel Input, 1 channel Output, RCA |
| Audio: | 2-Way Radio; Codec Support G-711U, G-711A, G726. |
| User Interface: | Web, Local GUI |
| AI By Camera: | Face Detection; Face Recognition; Perimeter Protection; SMD |
| AI By Device: | Face Detection; Face Recognition; Perimeter Protection |
| Video Output: | 1 × VGA, 1 × HDMI (max. resolution: 4K) (simultaneous) |
| Perimeter Performance AI By Device: | 1 |
| Perimeter Performance AI By Camera: | 4 |
| Face Detection Performance: | 1(Up to 12 Face Image/Second) |
| Face Attributes: | 6 attributes: Gender; age group (6); glasses; expressions (8); mouth mask; beard |
| Face Detection Performance of AI By Camera: | 5 |
| Face Database Capacity: | 10 faces with 5000 Images |
| Face Recognition Performance of AI By Device: | 1 (up to 4 Face Images/Second) |
| Face Recognition Performance of AI By Camera: | 5 |
| SMD By Camera: | 4-channel SMD (AI by camera): Detects tripwire and intrusion of human or vehicle; filters false alarms caused by leaves, raindrops and change of brightness away |
| Video Recording: | 320Mbps |
| Video Display Split: | 1/4/8/9/16 |
| Network Bandwidth: | Throughput: 360Mbps, Uplink: 160Mbps, Downlink: 256Mbps |
| Resolution: | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc. |
| Compression: | Smart H.265+/H.265/Smart H.264+/H.264/MJPEG |
| OSD: | Camera Title, Time, Camera Lock, Motion Detection, Recording |
| Trigger Events: | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Motion Detection: | MD Zones: 396(22×18) |
| Video Loss/Camera Blank: | Support |
| Alarm Input/Output: | In:8Ch/Out:4Ch |
| General Alarm: | Motion detection; privacy masking; video loss; local alarm; PIR alarm; IPC alarm |
| Anomaly Alarm: | Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception |
| Intelligent Alarm: | Face detection; face recognition; perimeter protection (intrusion and tripwire); IVS; SMD |
| Alarm Linkage: | Record; snapshot; buzzer; log; preset; email; tour |
| Smart Phone: | iPone, iPad, Android |
| Smart Phone: | iPhone, iPad, Android Phone |
| Hard Disk: | 1 SATA III ports, up to 10TB Each, 1 eSATA Port |
| Array Type: | Hot Swappable HDD Interface with Raid0, Raid1, Raid5, Raid6, Raid10 |
| Disk Group and Quota: | Support as per Video Channel |
| Bit Rate: | 64Kbps ~ 10Mbps Per Channel |
| Decoding Capability: | 1-channel: 12MP@30fps; 1-channel 8MP@30fps; 2-channel 5MP@30fps; 3-channel 4MP@30fps; 6-channel 1080p@30fps |
| Audio Compression: | PCM: G.711A; G.711U; G.726 |
| RCA: IN/Out: | 1/1 |
| Recording Mode: | Manual, Schedule (Regular/ Continuous), Motion Detection, Line Crossing, Perimeter Intrusion |
| Intelligent Video: | Support Motion Detection, Camera Tempering Detection, Perimeter Intrusion Detection |
| Search Mode: | Time, Calendar, Channel Search, Event Search, (ANR, Regular Video, Motion Detection Video, Alarm Video, Intelligent |
| Sync Playback: | 1/4/9/16 |
| Encryption: | Support Encrypted Recording from IP Camera to NVR |
| Playback Function: | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Playback Mode: | Instant Playback, Local Video, Local Image, External File Playback |
| Smart Features: | MD, Tripwire, Intrusion Detection, Video Loss, People Counting, Face Detection, Face Recognition, ANPR, AI |
| Backup Location: | Local, Network, IPSAN, NAS |
| Backup Mode: | Flash Drive, External USB Storage/Hard Disk, NAS. |
| Interface Ports: | 2 USB Ports (2 Rear USB 3.0, 1 Front USB 2.0), 1 RS485, 1 RS232 |
| Max User Access: | 128 Users |
| Record Interval: | 1~120 min (default: 60 min), Pre-record: 1~60 sec, post-record: 1~60 sec |
| Ethernet: | 2 RJ-45 port (10/100M/1000Mbps) Independent or Joint Working |
| Protocols: | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search; RTSP; Auto Registration; ONVIF (profile T; profile S; profile G); CGI; SDK |
| Power Supply: | Single, AC100V ~ 240V, 50 ~ 60 Hz, 12VDC, 3.33A |
| Power Consumption: | <10W Without HDD |
| Operating Temperature: | 0°C~55°C |
| Working Temp: | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Operating Altitude: | 3000M |
| Mounting: | 2U Rack Mountable with Rack Mounting Bracket |
| Casing: | Metal |
| Certification: | ISO, CE, FCC, ROHS |
| Country of Origin: | India |
