Key Features-
- Intel Processor
- Max 8 IP Camera Inputs with IVS Recording
- Max 256/128 Mbps Incoming/Outgoing Bandwidth
- Up to 8MP Resolution for Preview and Playback
- Expanded Storage Space
- Smart Tracking
- Intelligent Video System with Business Analytics (Two IP Channels)
- Dual-OS Design to Ensure High Reliability of System Running
- 264+ Compression Effectively Reduces the Storage Space and Costs by up to 50%
- HDMI1/VGA1 Outputs Provided
- HDMI1 Video Output Full HD Resolution
- Up to 2 SATA Interfaces for Recording and Backup
Specifications
| Feature | Details |
| Processor: | Industrial-Grade Embedded Processor |
| IP Camera Input: | 8 Channel |
| Operating System: | Embedded LINUX |
| Two-way Talk: | 1 channel Input, 1 channel Output, RCA |
| User Interface: | Web Operating in Local GUI |
| Video Output: | 1 VGA/1 HDMI Maximum Resolution 1080P |
| Video Recording: | 80Mbps for Access, 80 Mbps for Storage and 60 Mbps for Forwarding |
| Video Display Split: | 1/4/8/9 |
| Resolution: | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc. |
| Compression: | Smart H.265+/H.265/Smart H.264+/H.264/MJPEG |
| OSD: | Camera Title, Time, Camera Lock, Motion Detection, Recording |
| Trigger Events: | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Motion Detection: | Support |
| Video Loss/Camera Blank: | Support |
| Alarm Input/Output: | In:4Ch/Out:2Ch |
| Smart Phone: | iPhone, iPad, Android Phone |
| Hard Disk: | 2 SATA III ports, up to 10TB Each, 1 eSATA Port |
| Bit Rate: | 64Kbps ~ 10Mbps Per Channel |
| Decoding Capability: | AI disabled: 1-channel 12MP@30fps; 1-channel 8MP@30fps; 2-channel 5MP@30fps; 3-channel 4MP@30fps; 6-channel 1080p@30fps AI enabled: 1-channel 8MP@30fps; 1-channel 5MP@30fps; 2-channel 4MP@30fps; 4-channel 1080p@30fps |
| Recording Mode: | Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Stop |
| Search Mode: | Time/Date, Alarm, MD & Exact search |
| Sync Playback: | 1/4/9/16 |
| Playback Function: | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Smart Features: | MD, Tripwire, Intrusion Detection, Video Loss, People Counting, Face Detection, Face Recognition, ANPR, AI |
| Backup Mode: | USB Device/Network/eSATA Device |
| Interface Ports: | 2 USB Ports (1 Rear USB 3.0, 1 Front USB 2.0), 1 RS485, 1 RS232 |
| Max User Access: | 128 Users |
| Record Interval: | 1~120 min (default: 60 min), Pre-record: 1~30 sec, post-record: 10~300 sec |
| Ethernet: | 1 RJ-45 port (10/100M/1000Mbps) Independent or Joint Working |
| Protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search, ONVIF 2.4, SDK, CGI |
| Power Supply: | Single, AC100V ~ 240V, 50 ~ 60 Hz, DC 12V-1.5A |
| Power Consumption: | <10W Without HDD |
| Working Temp: | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Casing: | Metal/Plastic |
| Certification: | ISO, CE, FCC, ROHS |
| Country of Origin: | India |
