| Specification | |
|---|---|
| Type of Switch | Managed |
| Technology | Non PoE |
| Number of 1G Copper Ports | 24 |
| Number of 10G Copper Ports | 0 |
| Number of 1 G SFP Port (Uplink) | 0 |
| Number of 10 G SFP+ Port (Uplink) | 4 |
| Multi-Gigabit Support | No |
| Redundant Power supply ( from day one) | Not Available |
| Console Port | Available |
| Switching Capacity-Non Blocking (Gbps | 128 |
| Throughput (MPPS) | 95 |
| Operating System | Available |
| Dedicated Stacking Port/Slot ( from day one) | Not Available |
| Stacking Bandwidth (Gbps) | 0 |
| Basic Layer-3 Protocol | Static Route |
| Security Feature | L2/L3/L4 ACL; 802.1X Port Security with Radius CoA, dACL; Accounting & Dynamic VLAN Assignment; TACACS+ / RADIUS AAA; |
| Management Protocol | CLI and GUI options; Dual Stack (IPv4 and IPv6) Management; Telnet, SSHv2 and SNMP v1/v2/v3 support; NTP, FTP, TFTP, |
| QoS | Up to eight priority queues, Rate Limiting/Policing, CIR/ EIR, Shaping (SPQ / WRR/ WFQ) |
| Operating Temperature Range (Degree C) | -10~50°C |
| Operating Humidity (RH)(%) | 10%~90% |
| IPv6 Ready from day one and dully certified | Yes |
| PoE Power Budget ( Watt ) | 0 |
| On Site OEM Warranty | 5 Year |
| Basic Layer-3 Protocol; Support 4094 VLAN IDs, 16K MAC Table, Voice VLAN; L2 Loop Avoidance – STP/RSTP, MSTP, ERPS, STP Root and Edge Port Protection; Multicast – IGMP v1/v2/v3 Snooping, IGMP filtering, IGMP proxy | Static Route; Yes; Yes; Yes |
| Security Feature | L2/L3/L4 ACL; 802.1X Port Security with Radius CoA, dACL; Accounting & Dynamic VLAN Assignment; TACACS+ / RADIUS AAA; DHCP snooping, ARP Inspection, IPv6 ND; Inspection; MAC-IP Anti spoofing, MAC Address Notification; Inherent DoS Attack Prevention; Storm Control -Broadcast, Multicast and Unknown Unicast |
| Management Protocol | CLI and GUI options; Dual Stack (IPv4 and IPv6) Management; Telnet, SSHv2 and SNMP v1/v2/v3 support; NTP, FTP, TFTP, SCP, SFTP, Port Mirroring, Traceroute; DHCP Relay & Client; Built- in Event Policy / Scheduler Framework for Automation; Zero Touch Provisioning |
| QoS; Certifications | Up to eight priority queues, Rate Limiting/Policing, CIR/ EIR, Shaping (SPQ / WRR/ WFQ), Multi-Field (802.1p / DSCP) Classification and Remarking; Environment: IEC 600682, QM- 333, RoHS • EMI/EMC: EN 55024, EN 55032, CISPR 24, CISPR 32, IEC 61000-4 • Safety: EN 62368-1, IEC 62695-11-10, IEC 60320-1 • Software: IPV6 Ready Logo Certified |
| Operating System; Stacking Bandwidth (Gbps);IPv6 Ready from day one and dully certified; Static Routing & InterVLAN Routing; 802.1q and QinQ (Port based and Selective),MVRP; LLDP/LLDP MED to identify end points, IP Phones etc.; Jumbo MTU upto 9198 Bytes | Available; 0; Yes; Yes; Yes; Yes; Yes |
