Products Feature:
1.100W/130W/200W Low illumination CMOS sensor
2.720P/960P/1080P Resolution, Clear and exquisite image；
3.HD Lens 3.6mm；
4.ICR automatically switch to achieve day and night monitoring；
5.Automatic electronic shutter, to adapt to different monitoring environment；
6.Infrared distance: 3 high-power infrared light 20 meters to 30 meters；
7.IP66 waterproof design
8.Support digital WDR, 3D noise reduction；
9.H.264 video compression technology, high quality, low bit rate；
10.Support mobile remote monitoring (iOS, Android)；
11.Multiple browser access (IE、Chrome、Firefox、Safari)；
12.Support information overlay (such as: ID, IP, DDNS information, etc.)；
13.Supports WEB, CMS, VMS, MYEYE, cloud services；
14.Supports connection with HVR / NVR and support standard Onvif protocol
15.Support IEEE802.11b / g / n transmission, dual antenna, 2.4GHz band, transmission 150Mbps
16.Screen Size: 10.5”;
17.HDD Supported: 2.5”*1pcs;
Application:
Warehouses, underground parking, bars, pipelines, parks and other environments with low or no light but require high-definition quality images.
| Parameter of WIFI NVR: | |
|---|---|
| Model | SMT-N3104W |
| 4CH WirelessI 960P HD-NVR | |
| Main processor | HI 3520D V200 |
| Operating System | Embedded Linux |
| Video compression | H.264 High Profile Lever 4.2 |
| Video output | 720P60,XGA,960P60 |
| Video input(IP) | 4*960P |
| Audio compression | G.711 |
| intercom | None |
| Recording mode | Manual/Alarm/Video Detection/Continuous |
| Local Playback | 4*960P/4*720P |
| Record Storage | HDD、Network |
| Backup mode | Network backup, USB hard disk,SB burner, SATA burner |
| Protocol | TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,,P2P |
| Video output | 1ch HDMI |
| Audio I/O | None |
| Alarm I/O | None |
| Network interface | 4*RJ45 10M/100M Adaptive Ethernet port+4ch WIFI |
| USB | 2*USB 2.0 port |
| Hard disk | 1SATA(Up to 6TB) |
| Power supply | DC +12V /2A |
| Power Consumption | 5W（Without HDD） |
| Work environment | Temperature:-10℃－＋55℃, Humidity:10%-90%RH |
| Onvif | None |
| Size | 250mm*150mm*40mm |
| Weight | About 3700g |
| Parameter of WIFI Camera : | |
|---|---|
| Model | SMT-N6283W |
| 1.0MP 、 1.3MP 、 2.0MP | |
| Image sensor | 1/4″ CMOS 、1/3″ CMOS 、1/2.8″ CMOS |
| Chipset | H62+ HI 3518E V200 、 HI3518E V200+AR0130、HI3518E V200+324 |
| Min. Illumination | Color：0.1Lux @(F1.2,AGC ON); 0 Lux with IR |
| B/W：0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
| S / N ratio | ≥44dB |
| Shutter speed | 1/5 – 1/10000s |
| Day & Night | Day / Night / External control（IR Cut Filter） |
| AGC | Auto / Manual |
| White balance | Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| Wide dynamic range | Digtal Wide dynamic range |
| Digital noise Reduction | 2DNR,3DNR |
| Video Compression | H.264 Main Profile/ |
| Audio Compression | G711 |
| Max.Image Resolution | 1280×720@25fps、1280×960@25fps、1920×1080@25fps |
| Image Resolution | Main stream （1280×720、720×576、640×480） |
| sub-stream （640×480、352×288、320×240、176×144） | |
| Bitrate | CBR/VBR, bitrate：256Kbps~10Mbps variable |
| Lens | 3.6mm HD lens |
| Motion detect | Support |
| P2P | Android、IOS 、Xmeye Mobile App |
| Protocols | TCP/IP，HTTP，NTP，DHCP，UDP，ARP，DDNS，DNS，P2P |
| Onvif | Support |
| Network | 10/100M Base-TX Ethernet, RJ45 Connector |
| Wireless | Frequency:2.4G |
| transmission distance :More than 120 meters with no obstacle， More than 30 meters if penetrate the wall，The actual transmission distance according to the situation | |
| Power supply | DC12V/1A |
| Working Temperature | -30°C ~60°C, Humidity≤90%RH(Unsupport-condensing) |
